TNC635R - ThermNight Thermal & Night Vision Multispectral Scope with Laser Rangefinder and Ballistic Calculator

Mount Type: PMS - Picatinny 0 MOA Short

$3,159.99
$3,699.99
$3,159.99
Subtotal: $3,159.99
 Free Shipping
 3-Year Warranty for TNC635R ( Extended Warranty )
 30-Day Returns
 Free Accessory Pack - 21700 Battery X2 and Battery Charger
TNC635R - ThermNight Thermal & Night Vision Multispectral Scope with Laser Rangefinder and Ballistic Calculator

TNC635R - ThermNight Thermal & Night Vision Multispectral Scope with Laser Rangefinder and Ballistic Calculator

$3,699.99 $3,159.99

TNC635R - ThermNight Thermal & Night Vision Multispectral Scope with Laser Rangefinder and Ballistic Calculator

$3,699.99 $3,159.99

    See it All You Will Love What You See

    The ThermNight Multispectral series of scopes is the culmination of technology to create the perfect aiming solution. It can be used in all weather & lighting conditions. The thermal and night vision combination allows for faster detection of targets and provides high-quality digital image for identification.

    Thermal & Night Vision Combination

    Ballistic Calculator

    Day & Night in All Conditions

    Ultra Compact & Light Weight

    High-End Thermal Sensor, Enhanced Visibility

    The TNC335R features a 384 x 288 thermal sensor, while the TNC635R offers a 640 x 512 thermal sensor, delivering superior clarity with a wider field of view (FOV) for easier target detection. Both models use uncooled VOx microbolometers with a 12um pixel pitch, ≤18mk@25°C sensitivity, and a 50Hz refresh rate for optimal performance in the field.

    Loading...

    TNC635R

    Be The Ultimate Predator And See In The Dark With The Sony Starvis 2 Sensor

    Starvis2 SONY Digital Sensor

    Enhanced Algorithm

    1920x1080 Micro-OLED

    Utilization of SONY's latest CMOS Starvis2 Technology, as well as ED glass lenses, cutting edge AI imaging algorithms and a world-leading 60Hz 1920x1080 Micro-OLED display ensures the DNT ThermNight to be perfect for day or night.
    Loading...

    Night Vision And Thermal At The Touch of a Button

    Switching between thermal and digital channels is as easy as the press of a button, conveniently positioned on the side of the scope. You can also enable Picture-in-Picture so you can see both channels at the same time, saving you time to focus on your target.
    Loading...

    Range To Target With Instantaneous Ballistic Solution

    Featuring a cutting-edge built-in laser rangefinder, this device provides highly accurate distance measurements from 5 to 1100 yards. Once the range is determined, the onboard ballistic calculator quickly generates a ballistic solution, which is then displayed as either dial-in or holdover corrections, ensuring precision with every shot.

    More features

    Thermal ZOOM Lock

    One-shot Zeroing

    Detachable IR llluminator

    Up to 5 hrs Battery Life

    Built-in 64Gb Storage

    Reticles: 8 Styles and 5 Colors

    Precise aiming even in the Picture-In-Picture mode

    Wireless Updates

    Package Contents

    TNC635R
    ×1
    PMS
    ×1
    PM20L
    ×1
    Eye Cup
    ×1
    Flip Up Cover
    ×1
    21700 Flat Top Battery
    ×2
    Charger
    ×1
    USB Cable
    ×2
    User Manual
    ×1
    Lens Cleaning Cloth
    ×1

    Learn More >

    -TNC635R SPECIFICATIONS-

    Physical Specifications


    Net Weight
    Dimensions
    Storage
    724g/25.6oz
    232x82x78mm/9.2x3.2x3.0 inches
    Bulit-in memory,64GB
    LRF Maximum Measuring Range
    WIFI/APP
    Shock Resistance
    5~1100M/5~1200yds
    Yes(DNT)
    800Gs
    Ingress Protection
    Operating Temperature
    IP67
    -20~50°C/-4°F~122°F

    Display Specifications


    Type
    Display Resolution
    Frame Rate
    Micro-OLED
    1920x1080 pixels
    60Hz

    Battery Power Supply


    Battery Type
    Operating Time
    External Power Supply
    21700 Battery(flat top)
    5.5h
    5V - Type C USB

    THERMAL CHANNEL - Sensor Specifications


    Resolution
    Field of View(FOV)
    Frame Rate
    640x512 pixels
    12.52° x 10.02°
    50FPS
    Base Magnification
    Digital Zoom
    Focal Length of Objective Lens
    1.5x
    1.5x, 2.25x,3x,3.75x,4.5x,5.25x, 6x
    35mm
    Pixel Size
    NETD
    Image Sensor
    12x12um
    ≤18mk@25℃
    Uncooled lnfrared lmage Sensor

    VISIBLE LIGHT CHANNEL - Sensor Specifications


    Resolution
    Sensor Frame Rate
    Video Record Resolution
    1920*1080 pixels
    60Hz
    1800x1080 pixels

    VISIBLE LIGHT CHANNEL - Optical Specifications


    Detection Range
    Field of View(FOV)
    Eye-Relief
    400m
    5.31° x 2.99°
    65mm
    Base Magnification
    Digital Zoom
    Diopter Adjustment
    5X
    5X,7.5X,10X,12X,15X,17.5X,20X
    ±3D
    IR Rating
    IR Wavelength
    Class 3R Eye Safe
    850/940nm


    Net Weight
    724g/25.6oz
    Dimensions
    232x82x78mm
    9.2x3.2x3.0 inches
    Storage
    Bulit-in memory,64GB
    LRF Maximum Measuring Range
    5~1100M/5~1200yds
    WIFI/APP
    Yes(DNT)
    Shock Resistance
    800Gs
    Ingress Protection
    IP67
    Operating Temperature
    -20~50°C/-4°F~122°F


    Type
    Micro-OLED
    Display Resolution
    1920x1080 pixels
    Frame Rate
    60Hz


    Battery Type
    21700 Battery(flat top)
    Operating Time
    5.5h
    External Power Supply
    5V - Type C USB


    Resolution
    640x512 pixels
    Field of View(FOV)
    12.52° x10.02°
    Frame Rate
    50FPS
    Pixel Size
    12x12um
    NETD
    ≤18mk@25℃
    Image Sensor
    Uncooled Infrared Image Sensor
    Base Magnification
    1.5X
    Digital Zoom
    1.5x,2.25x,3x,3.75x,
    4.5x,5.25x, 6x
    Focal Length of Objective Lens
    35mm


    Resolution
    1920*1080 pixels
    Sensor Frame Rate
    60Hz
    Video Record Resolution
    1800x1080 pixels


    Detection Range
    400m
    Field of View(FOV)
    5.31° x 2.99°
    Eye-Relief
    65mm
    Digital Zoom
    5X,7.5X,10X,12X
    15X,17.5X,20X
    Base Magnification
    5x
    Diopter Adjustment
    ±3D
    IR Wavelength
    850/940nm
    IR Rating
    Class 3R Eye Safe

    Customer Reviews

    Based on 21 reviews
    95%
    (20)
    5%
    (1)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    J
    J.
    DNT635

    I finally had a chance to zero the 635 and take it out into the field a few times. I'm more than a little impressed so far. Day/night/thermal images are impressive. Although I always zero thermal/day independently the ability to freeze PIP and move the reticle is outstanding. In thermal target detection for me up to now is easily 300 yards for rats and mice. At 300 yards target ID coyotes and rabbits is super clear. So detection and ID will be much farther. Build quality seems very good and with all the features and price point with this scope I would definitely recommend it.

    #
    #.A.Z.
    Dnt635r

    Amazing product. Wish it can be use as clip on like hydra series.

    S
    S.
    Wow

    I've used multiple different night vision scopes of various types.... And after using this for a half hour this is way higher quality than all the previous ones.... Everything is just exactly as it should be ....almost one button touch for every feature... One shot zero works perfect.... Ballistic calculator works great...I had a Pard nv scope before this.... And it had a lot of great features but it always lacked on those small details ,like when you range found something a long ways away The pip would stay centered on the original point of aim not the range found point.... Just dumb... But the therm night... Everything works perfectly absolutely awesome.... You can update the firmware through your phone wirelessly get videos wirelessly.... Everything works perfect....
    You can definitely tell somebody that has been out and hunted and knew what we needed made this..... AND THEY ACTUALLY TESTED IT BEFORE SELLING IT.... And it shows
    GREAT job DNT.....

    S
    S.S.
    Just buy it. You won't regret it.

    This thing is incredible. If I had a nitpick to make, it would be that it's too much for my use. I have it mounted on a 30 caliber airgun rifle. Because the magnification starts at 5x, it's a bit much for the limited range of the rifle. But that's fine. I can put this one on a longer range rifle and it will be just fine.

    d
    d.g.
    tnc635r

    received in nice protected box. charged batteries and inserted for backyard play. learning buttons and view options. performed a few vid scans with ease. dl app , sync iphone easily and added a few ballistic charts. will take out to range to zero. overall worked as expected.
